Ratchet Strap For US
Please Note:
If you have any special requirements, you can contact us bellow and we will reply you as soon as possible.
Request A QuoteProduct Specification:
Ratchet Straps For North America Acc. to ASTM B30.9,WSTDA
Wristrong produces 1",2'',3'' and 4'' Ratchet tie down straps suitable for North American market to ASTMB30.9, WSTDA,our ratche tie down are made of durable rein-coated,UV-resistant polyester webbing strap,and various heavy duty corrosion resistant ratchet buckle and end fittings .Specs Of Wristrong USA Standard Ratchet Straps:
Material:Polyester webbing + Mn steel
Safety Factor: 2:1, 3:1
Length: As requested
Color: White,Yellow,Green,Black,Pink,Red,etc
Standard: ASTM B30.9,WSTDA
Characteristic:Fast tension and release,wearable
Package: Carton boxes+pallets
Wristrong China also manufactures one piece (endless) assembly for use without end fittings.The tie down strap can be stenciled with customer's company name or logo,and the color,length,width etc can be made to client's special requirements. Please refer to our professional Sales Team for your details requirements.1" RATCHET & CAM BUCKLE TIE DOWN
 |
ITEM NO. | BUCKLE | LENGTH | END FITTING | M.B.S. |
| RSFH110 | RATCHET | 10' or As requested | FLAT HOOK | 1,000LBS | |
| CSFH110 | CAM | 10' As requested | 1,000LBS | ||
 |
|||||
| RSSH110 | RATCHET | 10' As requested | STAMPED SNAP HOOK | 2,100LBS | |
| CSSH110 | CAM | 10' As requested | 1,000LBS | ||
 |
RSWH110 | RATCHET | 10' As requested | DOUBLE J HOOK | 2,100LBS |
| CSWH110 | CAM | 10' As requested | 1,000LBS | ||
 |
RSHK110 | RATCHET | 10' As requested | HOOK & KEEPER | 2,100LBS |
| CSHK110 | CAM | 10' As requested | 1,000LBS | ||
 |
RSOH110 | RATCHET | 10' As requested | S HOOK (Vinyl Coated or Zinc Plated) | 2,100LBS |
| CSOH110 | CAM | 10' As requested | 1,000LBS | ||
 |
RSEL110 | RATCHET | 10' As requested | ENDLESS | 2,100LBS |
| CSEL110 | CAM | 10' As requested | 1,000LBS |
2" RATCHET TIE DOWN
 |
ITEM NO. | STRAP | END FITTING | M.B.S. |
| RSDJ227 | 2" X 27' | DOUBLE J HOOK | 10,000LBS | |
| RSDJ230 | 2" X 30' | |||
 |
RSFH227 | 2" X 27' | FLAT HOOK | 10,000LBS |
| RSFH230 | 2" X 30' | |||
 |
RSGH227 | 2" X 27' | CHAIN GRAB HOOK | 10,000LBS |
| RSGH230 | 2" X 30' | |||
 |
RSSH227 | 2" X 27' | TWISTED SNAP HOOK | 10,000LBS |
| RSSH230 | 2" X 30' | |||
 |
RSCH227 | 2" X 27' | CHAIN ANCHOR ASSEMBLIES | 10,000LBS |
| RSCH230 | 2" X 30' | |||
 |
RSDR227 | 2" X 27' | DELTA RING | 10,000LBS |
| RSDR230 | 2" X 30' | |||
 |
RSLFH227 | 2" X 27' | FLAT HOOK | 5,000LBS |
| RSLFH230 | 2" X 30' | |||
 |
RSLDR227 | 2" X 27' | DELTA RING | 5,000LBS |
| RSLDR230 | 2" X 30' |
2" LOGISTIC TIE DOWN
 |
ITEM NO. | STRAP | END FITTING | BUCKLE | M.B.S. |
| WLRB212 | 2" X12' | E Track Fitting | RATCHET | 3,000LBS | |
| WLRB216 | 2" X16' | ||||
 |
WERB212 | 2" X12' | 3 Piece End Fitting | RATCHET | 3,000LBS |
| WERB216 | 2" X16' | ||||
 |
WLCB212 | 2" X12' | E Track Fitting | CAM BUCKLE | 2,500LBS |
| WLCB216 | 2" X16' | ||||
 |
WBCB212 | 2" X12' | Butterfly Fitting | CAM BUCKLE | 1,250LBS |
| WBCB216 | 2" X16' |
3" /4" RATCHET TIE DOWN
 |
ITEM | STRAP | END FITTING | M.B.S. |
| RSDJ327 | 3" X 27' | DOUBLE J HOOK | 15,000LBS | |
| RSDJ430 | 4" X 30' | |||
 |
RSFH327 | 3" X 27' | FLAT HOOK | 15,000LBS |
| RSFH430 | 4" X 30' | |||
 |
RSGH327 | 3" X 27' | CHAIN GRAB HOOK | 15,000LBS |
| RSGH430 | 4" X 30' | |||
 |
RSCH327 | 3" X 27' | CHAIN ANCHOR ASSEMBLIES | 15,000LBS |
| RSCH430 | 4" X 30' | |||
 |
RSFT327 | 3" X 27' | FORGED TRIANGLE | 15,000LBS |
| RSFT430 | 4" X 30' |
WINCH STRAP
 |
ITEM NO. | STRAP | END FITTING | M.B.S. |
| WSFH227 | 2" X 27' | FLAT HOOK | 10,000LBS | |
| WSFH230 | 2" X 30' | |||
 |
WSFH327 | 3" X 27' | FLAT HOOK | 12,000LBS |
| WSFH330 | 3" X 30' | |||
| WSFH427 | 4" X 27' | FLAT HOOK | 15,000LBS | |
| WSFH430 | 4" X 30' | |||
 |
WSFT327 | 3" X 27' | FORGED TRIANGLE | 12,000LBS |
| WSFT330 | 3" X 30' | |||
| WSFT427 | 4" X 27' | FORGED TRIANGLE | 15,000LBS | |
| WSFT430 | 4" X 30' | |||
 |
WSGH327 | 3" X 27' | CHAIN GRAB HOOK | 12,000LBS |
| WSGH330 | 3" X 30' | |||
| WSGH427 | 4" X 27' | CHAIN GRAB HOOK | 15,000LBS | |
| WSGH430 | 4" X 30' | |||
 |
WSCH327 | 3" X 27' | CHAIN ANCHOR ASSY | 12,000LBS |
| WSCH330 | 3" X 30' | |||
| WSCH427 | 4" X 27' | CHAIN ANCHOR ASSY | 15,000LBS | |
| WSCH430 | 4" X 30' | |||
 |
WSDJ327 | 3" X 27' | DOUBLE J HOOK | 12,000LBS |
| WSDJ330 | 3" X 30' | |||
| WSDJ427 | 4" X 27' | DOUBLE J HOOK | 15,000LBS | |
| WSDJ430 | 4" X 30' | |||
 |
WSSE327 | 3" X 27' | SEWN EYE | 12,000LBS |
| WSSE330 | 3" X 30' | |||
| WSSE427 | 4" X 27' | SEWN EYE | 15,000LBS | |
| WSSE430 | 4" X 30' |
TOW STRAP
 |
ITEM NO. | STRAP | END FITTING | M.B.S. |
| TSHH220 | 2" X 20' | EYE HOOK | 10,000LBS | |
 |
TSEE220 | 2" X 20' | FLAT EYE | 10,000LBS |
| TSEE320 | 3" X 20' | 13,000LBS | ||
| TSEE420 | 4" X 20' | 15,000LBS |
